Safety & Anti-Slip Performance: The wet static friction coefficient is ≥ 0.65, enhanced to 0.7–0.75 for high-priority areas such as children’s zones and staircases, eliminating slipping risks for barefoot walking.
Durability & Scenario Adaptability: Resistant to immersion in chlorinated pool water and UV aging. After 5,000 friction tests, the anti-slip performance attenuation is ≤ 5%, with a service life of 8–10 years.
Comfort & Environmental Friendliness: Boasts excellent elastic cushioning performance, ensuring no discomfort when stepping barefoot. With VOC content ≤ 30g/L, it complies with health and environmental quality standards and has passed child safety contact certification.
Theme Compatibility: Supports customization of over 20 solid-color granules, enabling splicing of themed patterns like ocean waves and dolphins. It highly integrates with the water park’s scene style, serving both protective and decorative functions.
Core wet areas around pools, floors of parent-child wading zones, entrances and exits of shower rooms/locker rooms, walkway platforms, stair steps, landing areas of lazy rivers, and all other areas prone to wet slipping.
| Coating Structure | Material Type | Core Performance Indicators | Functional Role |
|---|
| High-Adhesion Primer Coat | Special Penetrating Primer | Bond strength ≥ 1.5MPa, penetration depth ≥ 2mm; compatible with concrete/old floor bases; seals base layer pores | Enhances base adhesion and prevents delamination and hollowing. |
| Elastic Cushion Layer | Elastic-Tough Anti-Slip Granule Mixture | Granule particle size: 1–3mm; mix ratio with adhesive 1:7; thickness: 8–10mm; impact absorption rate ≥ 40%; crack resistance | Absorbs impact and improves barefoot comfort. |
| Anti-Slip Functional Layer | Colored Elastic-Tough Anti-Slip Granule Mixture | Granule particle size: 0.3–1.0mm (0.3–0.6mm for children’s zones, 0.6–1.0mm for core zones); granule content adjustable from 20% to 30% | Forms 3D anti-slip texture to ensure wet safety. |
| Chlorine-Resistant Top Coat | Transparent Weather-Resistant Protective Coating | Hardness ≥ 60Shore D; resistant to hypochlorous acid corrosion; stain-resistant and easy to clean; dry film thickness: 0.2–0.3mm | Locks anti-slip granules in place and resists pool water erosion. |
Pre-Construction Preparation (1–2 Days)
Base Inspection: Verify that the base strength is ≥ C25, moisture content ≤ 8%, and flatness error ≤ 3mm/2m. Remove hollowing and cracks (cracks ≥ 0.3mm wide require V-groove repair).
On-Site Protection: Cover pool edges and equipment with masking film, set up temporary guardrails to avoid coating contamination.
Environmental Control: Maintain construction temperature between 5–35℃ and relative humidity ≤ 80%. Erect sunshades in open-air areas to prevent premature material curing due to direct sunlight.
Base Strengthening Treatment (1 Day)
Cleaning & Roughening: Rinse with a high-pressure water gun (80–100bar) and dry with oil-free compressed air, or perform sandblasting to Sa2.5 grade. Remove dust, oil stains, and moss to create a base surface with 50–80μm roughness.
Defect Repair: Level depressions with epoxy putty; fill expansion joints with special elastic adhesive for elastic-tough anti-slip flooring materials and smooth the surface. Grind all sharp corners to an arc transition with R ≥ 2mm.
Primer Application: Roll-coat the special penetrating primer for elastic-tough anti-slip flooring materials using a cross-hatch method to ensure even coverage without missed spots. Allow drying for 4–6 hours at 25℃ (proceed to the next process only after full curing).
Core Coating Construction (1–4 Days)
Elastic Cushion Layer Application: Mix black elastic-tough anti-slip granules with adhesive at a 1:7 ratio thoroughly. Pave with a special paver, control thickness at 8–10mm, and compact immediately with a 60kg roller to ensure a compactness ≥ 95%.
Anti-Slip Layer Forming: Adjust colored granule particle size and content according to area requirements (0.3–0.6mm/20% for children’s zones, 0.6–1.0mm/30% for core zones). After mixing, apply manually or via mechanical paving to a thickness of 5–6mm. Immediately comb anti-slip textures with a toothed squeegee after paving.
Top Coat Protection: After the anti-slip layer cures for 24 hours, spray the transparent chlorine-resistant protective coating with horizontal and vertical cross application to avoid bubbles and sagging. Ensure a dry film thickness of 0.2–0.3mm.
Curing & Acceptance (1–2 Days)
Curing Period: Close the site for 7 days, prohibit treading and water contact, and maintain ventilation and dryness to ensure full curing of the adhesive (optimal performance is achieved after 7 days at 25℃).
Finished Product Acceptance: Clean the site after curing, conduct tests on anti-slip coefficient, flatness, and bond strength. The area can be opened for use only after passing all tests.
| Area Type | Anti-Slip Enhancement Measures | Material Adjustment Points | Design Details |
|---|
| Core Zones Around Pools | Friction coefficient ≥ 0.7; granule content 30% | Adopt 0.6–1.0mm medium granules; increase top coat thickness to 0.3mm. | Add 3–5mm wide anti-slip stripes with 5cm spacing. |
| Parent-Child Wading Zones | Friction coefficient ≥ 0.65; gentle anti-slip without discomfort | Adopt 0.3–0.6mm fine granules; increase cushion layer thickness to 10mm. | Splice cartoon patterns and divide activity areas with different colors. |
| Stair Steps | Friction coefficient ≥ 0.75; add auxiliary anti-slip strips | Reserve 5cm wide anti-slip strips on step edges; increase granule content to 35%. | Create horizontal stripes on step treads and use warning colors on risers. |
| Shower Rooms/Locker Rooms | Balance anti-slip performance and easy cleaning; semi-matte surface treatment | Reduce granule protrusion height; add anti-fouling components to the top coat. | Use light-colored granules to easily identify water accumulation areas. |
In-Process Inspection
Test wet film thickness every 50㎡ to ensure total thickness (cushion layer + anti-slip layer) ≥ 15mm.
Prepare 3 sets of bond strength test specimens every 1000㎡; tensile test result ≥ 1.5MPa.
Monitor granule mixing ratio in real time to ensure sufficient adhesive dosage (prevent granule detachment).
Final Acceptance
Appearance: No bubbles, hollowing, or granule detachment; uniform color with color difference ΔE ≤ 2.0.
Performance: Wet friction coefficient ≥ 0.65 (≥ 0.7 for high-priority areas); no abnormalities after 48-hour chlorine immersion test.
Dual Guarantee of Safety & Comfort: The elastic structure combined with graded anti-slip granules meets wet anti-slip requirements while avoiding barefoot discomfort, suitable for tourists of all ages.
Outstanding Scenario Weather Resistance: The special chlorine-resistant top coat and high-adhesive granule mixture resist dual erosion from chlorinated pool water and UV rays, solving the common problems of floor aging and detachment.
Strong Theme Integration: Supports customized colors and patterns, which can be deeply integrated with the water park’s tropical or fairy-tale themes, enhancing the visual appeal of the scene.
Efficient Construction & Operation: Room-temperature construction requires no large-scale equipment; zoned construction minimizes impact on park operations. Daily cleaning only requires water rinsing, resulting in low maintenance costs.
